Unlock a safer, more efficient, and cost-effective method for manhole repairs!
Manhole chimneys either leak, causing high sewage treatment costs and overflow into lakes and streams, or are often not level with the road, causing a traffic hazard. Using the Mr. Manhole Method gives you the superpowers to effectively address bump and leak problems by quickly removing the manhole and replacing it with a new, structurally sound, watertight assembly. You can complete the repair smarter, faster, and safer in a fraction of the time required by conventional methods.
Engineers agree that round repairs are far superior to square repairs. Instead of using square cuts, the Mr. Manhole method uses round cuts, generating 20 percent less debris while using 20 percent less replacement material.
Cut the manhole frame from the surface using circular cutting technology with 20% less debris and 20% less replacement material.
Seamlessly pull the disconnected frame and lid from the surface with a lifting magnet, eliminating the need for long and tedious manual labor.
Replace the frame and lid with custom steel plate to the appropriate height, without having to rely on concrete adjusting rings which are prone to leaks.
Carefully mill the surface surrounding the steel plate. Once the surface is fully prepared, pave the area back evenly so that it is leveled with the surrounding roadway.
Cut through the asphalt with a circular manhole cutter and remove the steel plate with minimal effort. Finish by restoring the manhole to grade with a smooth, level finish.
|
|
|
|
|---|---|---|---|
| Cutting Diameter | 52” | 44” to 60” | 50” to 72” |
| Cutting Arms | Four | Six | Six |
| Cutting Depth | 14” | 14” | 16” |
| Weight (Cutter only) | 900 Lbs | 1200 Lbs | 1400 Lbs |
| Included Speedplate | Standard | Standard | Standard |
| Model 40 Auger Drive | 2” | 2.5” | 2.5” |
| Easy Drive | |||
| Lifting Magnet | |||
| Casting Lifter Bracket | |||
| Debris Shield | |||
| Quick Change Teeth Gun |
With the Mr. Manhole Method, you can fully focus on your work, confident that the repairs you make will be safe, durable, and eliminate leakage and constant adjusting due to material breakdown. This all leads to peace of mind for the safety of your crew, your city, as well as your wallet.
The pallets are plastic bagged and shrink-wrapped, so you can store them safely until needed. The materials are reasonably priced, and shipping is included in the price for the continental United States.
Feel free to take a look at what we offer and select the specifications that work for your city. If you have any questions, give us a call, fill out our online form, or reach out to us via email at [email protected]
We have had great success with the system including great support from the company. We like the ease and speed of the Mr. Manhole system as well as the great looks of the finished product. We are very pleased with the Mr. Manhole products.
For over 23 years, more than 700 installers across the globe have adopted our practical technique and next-gen technology, resulting in over 12,000 successful manhole repairs each year. Partner with us, and experience a risk-free, swifter, and more efficient way of manhole rehabilitation.
